ON Semiconductor TIL113SM

Name: TIL113SM
Brand: ON Semiconductor
SKU: TIL113SM
Price: 0.736 USD
Availability: InStock
Rating: 4.5 (778 reviews)

MFG Part Number: TIL113SM

Available Quantity: 89250 Pieces

Reference Price: USD 0.736

Our Price: We have a big discount, please contact us

Shipping Date: We can ship out today

Manufacturer: ON Semiconductor

Brief Description: - OPTOISO 4.17KV DARL W/BASE 6SMD

Lead Free Status / RoHS Status: RoHS Compliant (Lead Free)

Moisture Sensitivity Level (MSL): 1 (Unlimited)

Date Code (D/C): New

Product Category: Optoisolators - Transistor, Photovoltaic Output

Stock Resource: Franchised Distributor

Warranty: 360 days quality guarantee

Datasheet: TIL113SM.pdf

Request Quotation for TIL113SM

Company Name

Contact Person

Phone Number

Address

Email

Message

TIL113SM Specifications

Manufacturer Part Number	TIL113SM
Future Part Number	FT-TIL113SM
SPQ / MOQ	Contact Us
Packing Material	Reel/Tray/Tube/Others
Series	-
TIL113SM Status (Lifecycle)	In Stock
Part Status	Active
Number of Channels	1
Voltage - Isolation	4170Vrms
Current Transfer Ratio (Min)	300% @ 10mA
Current Transfer Ratio (Max)	-
Turn On / Turn Off Time (Typ)	5µs, 100µs (Max)
Rise / Fall Time (Typ)	-
Input Type	DC
Output Type	Darlington with Base
Voltage - Output (Max)	30V
Current - Output / Channel	150mA
Voltage - Forward (Vf) (Typ)	1.2V
Current - DC Forward (If) (Max)	80mA
Vce Saturation (Max)	1.25V
Operating Temperature	-40°C ~ 100°C
Mounting Type	Surface Mount
Package / Case	6-SMD, Gull Wing
Supplier Device Package	6-SMD
Country of Origin	USA/JAPAN/MALAYSIA/MEXICO/CN
TIL113SM Weight	Contact Us
Replacement Part Number	TIL113SM-FT
